Briggs & Stratton 950 Series Engine 208cc – 3/4″ Crankshaft, OHV, Cast Iron Sleeve, 9.5 ft-lbs Torque, Magnetron Ignition

Dependable Power for Demanding Outdoor Equipment

The Briggs & Stratton 950 Series Engine is built to deliver reliable, long-lasting performance for a wide range of outdoor power equipment. With 208cc of displacement and 9.5 ft-lbs of gross torque, this small gas engine provides the power you need to tackle tough jobs — from tilling gardens to clearing snow and running compressors.

Built to Last

At the heart of this engine is a Dura-Bore cast iron cylinder sleeve that resists wear and abuse while delivering superior oil control. The overhead valve (OHV) design keeps operating temperatures cooler and extends valve life, ensuring the engine runs smoothly season after season.

Reliable Start-Up Every Time

The Magnetron electronic ignition eliminates the need for maintenance-prone points and provides quick, dependable starts in any condition. The mechanical governor automatically adjusts throttle to deliver extra power when you need it most.

Smooth, Low-Vibration Operation

A dual ball bearing crankshaft supports smooth rotation and reduces vibration, even under heavy loads. The high-flow cylinder head produces up to 20% more power than conventional small engines, while the float feed carburetor ensures consistent fuel delivery for reliable throttle response.

Key Features:

• 208cc displacement – Strong power output for demanding tasks
• 9.5 ft-lbs gross torque – Handles tough jobs with ease
• 3/4″ x 2-27/64″ crankshaft – 5/16″ tapped with 3/16″ keyway
• Dura-Bore cast iron sleeve – Extended engine life and better oil control
• OHV design – Cooler operation, longer valve life
• Magnetron electronic ignition – Maintenance-free, reliable starts
• Dual ball bearing crankshaft – Reduced vibration, smooth operation
• Mechanical governor – Automatic power boost for challenging tasks

Specifications:

• Displacement: 208cc
• Gross Torque: 9.5 ft-lbs
• Crankshaft: 3/4″ diameter x 2-27/64″ length
• Shaft Tapped: 5/16″
• Keyway: 3/16″
• Ignition: Magnetron Electronic
• Cylinder: Cast Iron Sleeve
• Valve Design: OHV (Overhead Valve)
• Applications: Tillers, blowers, compressors

Whether you’re replacing a worn engine or building new equipment, the Briggs & Stratton 950 Series delivers the reliability and performance you can count on.
